Figure 9. Engine Interface Wiring Harness From Machine Installation

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
163

TM 5-3805-294-23-4

0509

INSTALLATION - Continued

HYEX03166

Figure 9. Engine Interface Wiring Harness From Machine Installation.

Connect engine interface wiring harness connector D01 (Figure 10, Item 64) to water in fuel sensor connector

(Figure 10, Item 65).

0509-10
