TM 5-3805-294-23-4
0525
FIELD MAINTENANCE
RIGHT-HAND CONSOLE SWITCH PANEL REPLACEMENT
INITIAL SETUP:
Equipment Condition
Tools and Special Tools
Machine safely parked and shut down
Tool Kit, General Mechanic's: Automotive
(TM 5-3805-294-10). (Volume 5, WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
Cab right-hand console cover removed.
(WP 0568)
Materials/Parts
Tags (Volume 5, WP 0797, Table 1, Item 52)
Time to Complete
Tie Wraps (Volume 5, WP 0797, Table 1, Item
0.6 Hour(s)
56)
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 144, Fig. 171 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Tag and mark, wires, connectors, and wiring harnesses prior to removal to ensure proper
installation.
Note position of each tie wrap and remove as required.
0525-1
