TM 5-3805-294-23-4
FIELD MAINTENANCE
STARTER POSITIVE CABLE REPLACEMENT
INITIAL SETUP:
Tools and Special Tools
Equipment Condition (cont.)
Tool Kit, General Mechanic's: Automotive (Volume
Negative battery cable disconnected. (WP 0521)
5, WP 0796, Table 2, Item 119)
Cooling compartment lower access cover
removed. (WP 0591)
Engine compartment lower access cover removed.
Materials/Parts
Tags (Volume 5, WP 0797, Table 1, Item 52)
Lockwasher (Volume 5, WP 0798, Table 1, Item
Time to Complete
17) Qty: 1
1.5 Hour(s)
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 73 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Tag and mark wires, connectors, and wiring harnesses prior to removal to ensure proper
installation.
1.
Remove three bolts (Figure 1, Item 1), washers (Figure 1, Item 2), and cover (Figure 1, Item 3) from panel
(Figure 1, Item 4).
0527-1
