TM 5-3805-294-23-4
0533
INSTALLATION - Continued
10
11
12
3
13
HYEX00531
Figure 5. Clamp Installation.
5.
Install clamp (Figure 6, Item 8) to hose (Figure 6, Item 3) and bracket (Figure 6, Item 9) with bolt (Figure 6,
Item 6) and washer (Figure 6, Item 7).
