TM 5-3805-294-23-4
FIELD MAINTENANCE
AIR CONDITIONER COMPRESSOR TO CONDENSER REFRIGERANT HOSE REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Tool Kit, Refrigeration
WP 0794)
(Volume 5, WP 0796, Table 2, Item 120)
Materials/Parts
Lubricating Oil, Refrigerant Compressor (Volume
Equipment Condition
Machine safely parked and shut down
5, WP 0797, Table 1, Item 27)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
Engine compartment lower access cover removed.
34)
Tie Wraps (Volume 5, WP 0797, Table 1, Item
56)
Air conditioner refrigerant recovered. (WP 0540)
O-ring (Volume 5, WP 0798, Table 1, Item 91)
Qty: 1
Time to Complete
O-ring (Volume 5, WP 0798, Table 1, Item 60)
3.5 Hour(s)
Qty: 1
Personnel Required
Utilities Equipment Repairer 91C (1)
References
TM 5-3805-294-24P: Fig. 125 (Volume 5,
WP 0794)
REMOVAL
NOTE
Note position of each tie wrap and remove as required.
Note routing of hose during removal to ensure proper installation.
1.
Remove bolt (Figure 1, Item 1), washer (Figure 1, Item 2), hose (Figure 1, Item 3), and O-ring (Figure 1, Item
4) from air conditioner compressor (Figure 1, Item 5).
0533-1
