TM 5-3805-294-23-4
FIELD MAINTENANCE
AIR CONDITIONER COMPRESSOR REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Tool Kit, General Mechanic's: Automotive
WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
Tool Kit, Refrigeration
(Volume 5, WP 0796, Table 2, Item 120)
Equipment Condition
Machine safely parked and shut down
Materials/Parts
Lubricating Oil, Refrigerant Compressor (Volume
(TM 5-3805-294-10). (Volume 5, WP 0794)
5, WP 0797, Table 1, Item 27)
Negative battery cable disconnected. (WP 0521)
Engine compartment lower access cover removed.
Rope (Volume 5, WP 0797, Table 1, Item 36)
Qty: 10 ft.
Cooling compartment lower access cover
Lockwasher (Volume 5, WP 0798, Table 1, Item
removed. (WP 0591)
11) Qty: 4
Air conditioner belt removed. (WP 0531)
O-Ring (Volume 5, WP 0798, Table 1, Item 60)
Air conditioner refrigerant recovered. (WP 0540)
Qty: 1
O-Ring (Volume 5, WP 0798, Table 1, Item 91)
Qty: 1
Time to Complete
3.6 Hour(s)
Personnel Required
Utilities Equipment Repairer 91C (1)
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 123, Fig. 124, Fig. 125
(Volume 5, WP 0794)
REMOVAL
1.
Remove bolt (Figure 1, Item 1), washer (Figure 1, Item 2), hose (Figure 1, Item 3), and O-ring (Figure 1, Item
4) from air conditioner compressor (Figure 1, Item 5).
0532-1
