TM 5-3805-294-23-4
FIELD MAINTENANCE
AIR CONDITIONER CONDENSER REPLACEMENT
INITIAL SETUP:
Tools and Special Tools
Equipment Condition (cont.)
Tool Kit, Refrigeration
Air conditioner refrigerant recovered. (WP 0540)
(Volume 5, WP 0796, Table 2, Item 120)
Air conditioner receiver-dryer removed.
Materials/Parts
Lubricating Oil, Refrigerant Compressor
Time to Complete
(Volume 5, WP 0797, Table 1, Item 27)
2.5 Hour(s)
O-ring (Volume 5, WP 0798, Table 1, Item 61)
Qty: 1
Personnel Required
Utilities Equipment Repairer 91C (1)
References
TM 5-3805-294-24P: Fig. 123, Fig. 125 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
1.
Remove bolt (Figure 1, Item 1), washer (Figure 1, Item 2), hose (Figure 1, Item 3), and O-ring (Figure 1, Item
4) from condenser (Figure 1, Item 5). Discard O-ring.
0534-1
