Figure 2. Condenser Installation.
Figure 1. Remove Wiring.

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  356    357    358    359    360  361  362    363    364    365    366
. . . . . . .
TM 5-3805-294-23-4
0535
FIELD MAINTENANCE
AIR CONDITIONER EVAPORATOR AND FREEZE SWITCH REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Tool Kit, General Mechanic's: Automotive
WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
Tool Kit, Refrigeration
WP 0538
(Volume 5, WP 0796, Table 2, Item 120)
Equipment Condition
Machine safely parked and shut down
Materials/Parts
Lubricating Oil, Refrigerant Compressor
(TM 5-3805-294-10). (Volume 5, WP 0794)
(Volume 5, WP 0797, Table 1, Item 27)
Negative battery cable disconnected. (WP 0521)
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
Air conditioner refrigerant recovered. (WP 0540)
34)
Seat removed. (WP 0580)
O-ring (Volume 5, WP 0798, Table 1, Item 60)
Cab rear tray and cover removed. (WP 0566)
Qty: 1
Cab rear wiring harness bracket removed.
O-ring (Volume 5, WP 0798, Table 1, Item 61)
(WP 0572)
Qty: 1
Time to Complete
Personnel Required
7.1 Hour(s)
Utilities Equipment Repairer 91C (1)
References
TM 5-3805-294-24P: Fig. 122, Fig. 124 (Volume 5,
WP 0794)
0535-1
