TM 5-3805-294-23-4
FIELD MAINTENANCE
CAB DOOR HOLD OPEN CATCH REPLACEMENT/ADJUSTMENT
INITIAL SETUP:
References
Tools and Special Tools
TM 5-3805-294-24P: Fig. 99 (Volume 5,
Tool Kit, General Mechanic's: Automotive
WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Materials/Parts
Tie wraps (Volume 5, WP 0797, Table 1, Item 56)
Equipment Condition
Twine (Volume 5, WP 0797, Table 1, Item 58)
Machine safely parked and shut down
Qty: 10 ft
(TM 5-3805-294-10). (Volume 5, WP 0794)
Retaining ring
Negative battery cable disconnected. (WP 0521)
(Volume 5, WP 0798, Table 1, Item 86)
Pilot shutoff lever removed. (Volume 5, WP 0752)
Qty: 1
Cab left-hand console cover removed. (WP 0564)
Screw (Volume 5, WP 0798, Table 1, Item 87)
Cab rear tray, rear cover, and air conditioner rear
Qty: 2
duct removed. (WP 0566)
Bolt (Volume 5, WP 0798, Table 1, Item 84)
Qty: 2
Time to Complete
1.5 Hour(s)
Personnel Required
Construction Equipment Repairer 91L (1)
REMOVAL
NOTE
Note positions and remove clips as required.
1.
Remove three screws (Figure 1, Item 1) and cover (Figure 1, Item 2) from panel (Figure 1, Item 3).
0555-1
