Figure 1. Left-Hand Console Removal.

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  532    533    534    535    536  537  538    539    540    541    542
. . . . .
TM 5-3805-294-23-4
0565
FIELD MAINTENANCE
CAB LEFT-HAND CONSOLE REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
(Volume 5, WP 0796, Table 2, Item 119)
Seat removed. (WP 0580)
Left-hand armrest removed. (WP 0553)
Left-hand pilot control valve grip removed. (Volume
Materials/Parts
5, WP 0726)
Retaining Ring (Volume 5, WP 0798, Table 1, Item
Pilot shutoff lever removed. (Volume 5, WP 0752)
106) Qty:  1
Cab left-hand console covers removed.
(WP 0564)
Pilot shutoff switch removed. (Volume 5,
Personnel Required
WP 0756)
Construction Equipment Repairer 91L (1)
Time to Complete
References
4.4 Hour(s)
TM 5-3805-294-24P: Fig. 106, Fig. 158 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
NOTE
Note position of bolt and spring pin prior to removal to ensure proper installation.
1.
Remove bolt (Figure 1, Item 1), spring pin (Figure 1, Item 2), and washer (Figure 1, Item 3) from pilot control
valve (Figure 1, Item 4).
0565-1
