TM 5-3805-294-23-4
0615
INSTALLATION - Continued
1, 2, 3
4
5, 6, 7
HYEX02187
Figure 12. Wiring Harness To Alarm Installation.
9.
Install red wire terminal (Figure 12, Item 3) to alarm (Figure 12, Item 4) with washer (Figure 12, Item 2) and
screw (Figure 12, Item 1).
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Install cab rear tray. (WP 0566)
2.
Install seat. (WP 0580)
3.
Install storage compartment door. (WP 0608)
4.
Install cab forward lower armor plate. (WP 0587)
5.
Connect negative battery cable. (WP 0521)
6.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
