TM 5-3805-294-23-1
0004
TROUBLESHOOTING SYMPTOM INDEX - Continued
Malfunction/Symptom
Troubleshooting Procedure
9.
Engine Idles Poorly .......................................................................................................................... WP 0119
10.
Engine Misfires - Runs Irregularly .................................................................................................... WP 0120
11.
Engine Oil Pressure High ................................................................................................................. WP 0121
12.
Engine Oil Pressure Low .................................................................................................................. WP 0122
13.
Engine Will Not Crank ...................................................................................................................... WP 0123
14.
Engine Control Unit (ECU) Does Not Communicate with
Service ADVISOR ............................................................................................................................ WP 0124
15.
Excessive Fuel Consumption ........................................................................................................... WP 0125
16.
Excessive Oil Consumption .............................................................................................................. WP 0126
17.
Fuel in Oil ......................................................................................................................................... WP 0127
18.
Fuel Supply Quality Check ............................................................................................................... WP 0128
19.
Glow Plug Check .............................................................................................................................. WP 0129
20.
High-Pressure Fuel Supply System Test ......................................................................................... WP 0130
21.
Low-Pressure Fuel Supply System Test .......................................................................................... WP 0131
MONITOR CONTROLLER (MON)
1.
DTC 13303.02 - Abnormal Thermister Temperature ........................................................................ WP 0132
2.
DTC 13304.02 - Abnormal REG Input H Level ................................................................................ WP 0133
3.
DTC 13306.02 - Abnormal Excavator Operation And Tests
(EEPROM) ....................................................................................................................................... WP 0134
4.
DTC 13308.02 - Abnormal CAN Communication ............................................................................. WP 0135
5.
DTC 13311.03 - Fuel Level Sensor Short Circuit ............................................................................. WP 0136
6.
DTC 13311.04 - Fuel Level Sensor Open Circuit ............................................................................. WP 0137
COOLANT HEATER
1.
DTC 010 Overvoltage - Shutdown .................................................................................. Volume 2, WP 0138
2.
DTC 011 Undervoltage - Shutdown ................................................................................ Volume 2, WP 0139
3.
DTC 012 Overheating (Software - Threshold Value) ...................................................... Volume 2, WP 0140
4.
DTC 014 Possible Overheating Detected (Differential Evaluation) ................................. Volume 2, WP 0141
5.
DTC 015 Operation Lock - Heater Has Overheated More Than
10 Times ......................................................................................................................... Volume 2, WP 0142
6.
DTC 017 Overheating Detected - EMERGENCY OFF
(Hardware Limit Value) .................................................................................................... Volume 2, WP 0143
7.
DTC 020 Glow Plug - Interruption ................................................................................... Volume 2, WP 0144
0004-5
