TROUBLESHOOTING SYMPTOM INDEX - Continued
Malfunction/Symptom
Troubleshooting Procedure
78.
DTC 656.06 - Injector #6 Circuit Has Low Resistance ..................................................................... WP 0092
79.
DTC 656.07 - Injector #6 Not Responding ....................................................................................... WP 0093
80.
DTC 656.13 - Injector #6 Calibration Fault ....................................................................................... WP 0094
81.
DTC 898.09 - Engine Speed Request Not Received or Timed
Out ................................................................................................................................................... WP 0095
82.
DTC 1136.00 - Engine Control Unit (ECU) Temperature Signal
Extremely High ................................................................................................................................. WP 0096
83.
DTC 1136.16 - Engine Control Unit (ECU) Temperature Signal
Moderately High ............................................................................................................................... WP 0097
84.
DTC 1172.03 - Compressor Inlet Temperature Signal Out of
Range High ...................................................................................................................................... WP 0098
85.
DTC 1172.04 - Compressor Inlet Temperature Signal Out of
Range Low ....................................................................................................................................... WP 0099
86.
DTC 1347.03 - Suction Control Valve Signal Out of Range High .................................................... WP 0100
87.
DTC 1347.05 - Suction Control Valve Circuit Has High
Resistance ....................................................................................................................................... WP 0101
88.
DTC 1347.07 - Fuel Rail Pressure Actual to Desired Mismatch ...................................................... WP 0102
89.
DTC 1569.31 - Engine in Power Derate Condition ........................................................................... WP 0103
90.
DTC 1638.09 - Hydraulic Oil Temperature Message Not
Received or Timed Out .................................................................................................................... WP 0104
91.
DTC 3509.03 - Sensor Supply #1 Voltage Out of Range High ........................................................ WP 0105
92.
DTC 3509.04 - Sensor Supply #1 Voltage Out of Range Low ......................................................... WP 0106
93.
DTC 3510.03 - Sensor Supply #2 Voltage Out of Range High ........................................................ WP 0107
94.
DTC 3510.04 - Sensor Supply #2 Voltage Out of Range Low ......................................................... WP 0108
95.
DTC 3511.03 - Sensor Supply #3 Voltage Out of Range High ........................................................ WP 0109
96.
DTC 3511.04 - Sensor Supply #3 Voltage Out of Range Low ......................................................... WP 0110
ENGINE OBSERVABLE
1.
Abnormal Engine Noise ................................................................................................................... WP 0111
2.
Charge Air System ........................................................................................................................... WP 0112
3.
Coolant in Oil or Oil in Coolant ......................................................................................................... WP 0113
4.
Engine Coolant Temperature Above Normal ................................................................................... WP 0114
5.
Engine Cranks/Will Not Start ............................................................................................................ WP 0115
6.
Engine Does Not Develop Full Power .............................................................................................. WP 0116
7.
Engine Emits Excessive Black or Gray Exhaust Smoke .................................................................. WP 0117
8.
Engine Emits Excessive White Exhaust Smoke ............................................................................... WP 0118
