TM 5-3805-294-23-1
0108
Sensors Using Sensor Supply #2 Voltage from ECU connector J03 - Continued
Engine Oil Pressure Sensor.
Control Unit Response
The ECU will try to maintain the engine operating envelope. Engine performance may be affected.
TROUBLESHOOTING PROCEDURE
Table 1. DTC 3510.04 - Sensor Supply #2 Voltage Out Of Range Low.
Test or Inspection
Corrective Action
Malfunction
1.
Verify key switch is in OFF
1.
Check For DTC
position (TM 5-3805-294-10).
3510.04 Active
Status Change With
(Volume 5, WP 0794)
Engine Interface
Wiring Harness
Connector P03 and
Engine Wiring
Harness Connector
P04 Disconnected.
2.
Remove engine compartment
lower access cover. (Volume
4, WP 0593)
3.
Disconnect engine wiring
harness connector P04.
(Volume 5, WP 0800, Figure
56)
4.
Disconnect engine interface
wiring harness connector
P03. (Volume 5, WP 0800,
Figure 55)
5.
Turn key switch to ON position,
but DO NOT START ENGINE
(TM 5-3805-294-10). (Volume
5, WP 0794)
6.
Clear and refresh DTCs. Many
new DTCs will be active, only
note if DTC 3510.04 is still an
active DTC. (Volume 3,
WP 0362)
0108-2
