TM 5-3805-294-23-4
0567
INSTALLATION - Continued
107
108
9
109
108
107
108
107
HYEX02836
Figure 22. Cab Mount Installation.
14.
Install air duct (Figure 23, Item 106) to cab (Figure 23, Item 9) with bolt (Figure 23, Item 104) and washer
(Figure 23, Item 105).
