TM 5-3805-294-23-4
0567
INSTALLATION - Continued
78
77
79
9
80, 81, 82
79
HYEX02831
Figure 27.
Cup Holder Installation.
25.
Install cup holder (Figure 27, Item 78) to cup holder housing (Figure 27, Item 79) with screw (Figure 27, Item
77).
26.
Install cab wire harness ground wire (Figure 28, Item 76) to cab (Figure 28, Item 9) with screw (Figure 28, Item
73), lockwasher (Figure 28, Item 74), and washer (Figure 28, Item 75).
