TM 5-3805-294-23-4
0567
INSTALLATION - Continued
66
65
9
68
67
72
71
73, 74, 75, 76
69
70
HYEX02830
Figure 28.
Accessory Wiring Harness Connect.
27.
Connect dome light wire harness connector (Figure 28, Item 71) to cab wiring harness connector (Figure 28,
Item 72).
28.
Connect wiper wiring harness connector (Figure 28, Item 69) to cab wiring harness connector (Figure 28, Item
70).
29.
Connect cab rear work light wiring harness connector (Figure 28, Item 67) to cab wiring harness connector
(Figure 28, Item 68).
30.
Connect cab front work light wiring harness connector (Figure 28, Item 65) to cab wiring harness connector
(Figure 28, Item 66).
31.
Connect left speaker wire connector (Figure 29, Item 63) to cab wire connector (Figure 29, Item 64).
