TM 5-3805-294-23-4
0572
INSTALLATION - Continued
2
1
4
3
HYEX02592
Figure 40. Connect Auxiliary Fuse Box Wiring Harness.
26.
Connect wiring harnesses red wire (Figure 40, Item 1) to auxiliary fuse box wiring harness W13 black wire
connector AUX 3/X63 (Figure 40, Item 2).
27.
If armored cab is installed, install camera power supply TM 5-3805-295-13&P. (Volume 5, WP 0794)
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Install cab rear tray and rear cover. (WP 0566)
2.
Install seat. (WP 0580)
3.
Install seat belt. (WP 0579)
4.
Connect negative battery cable. (WP 0521)
5.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
